    Industrial Process Uncooled Infrared Camera Module With 8um-14um Spectral Range

    Ask Lasest Price
    Brand Name : Guide
    Model Number : Plug417R
    Supply Ability : 100000 Piece/Pieces per Month
    Price : Negotiable
    • Product Details
    • Company Profile

    Industrial Process Uncooled Infrared Camera Module With 8um-14um Spectral Range

    Industrial Process Uncooled Infrared Camera Module With 8um-14um Spectral Range
    Product Description

    OR2 General Thermal Module for Temperature Measurement features by 384*288 resolution, different lens for options, industrial-standard open interfaces and general protocol, it is designed for the applications such as electrical inspection, industrial production line’s inspection and OEM integration.

    This module supports digital video signals output and full radiometric pictures and compressed video’s storage. Its compatibility and extensibility make it could be simply redeveloped or integrated into any optoelectronic system.

    Product Overviews

    Industrial Process Uncooled Infrared Camera Module With 8um-14um Spectral RangeIndustrial Process Uncooled Infrared Camera Module With 8um-14um Spectral Range


    Specifications

    Plug417R

    Detector

    IR resolution

    400×300

    Pixel size

    17μm

    NETD

    <50mk/f1.0/25℃

    Spectral Range

    8~14μm

    Lens

    Focal Length

    7mm/f1.1,19mm/f1.0

    Focus

    Fixed/Manual/Electric

    Image Processing

    Frame rate

    9Hz,25Hz/50Hz(PAL),30Hz/60Hz(NTSC)

    Analog video

    PAL/NTSC

    Digital zoom

    1-8x continual zoom, step size 1/8

    Color palettes

    9 standard(customized, on demand)

    Boot screen

    Customized

    Boot time

    <15S

    AGC

    Yes,adaptive dynamic range compression

    IIE

    Intelligent gain control

    SDK

    Support secondary development

    Interface

    Standard external interface

    50Pin_HRS interface:DF12-50DS-0.5V(86)

    Control

    Communication protocol

    RS232

    Baud rate

    115200(default)

    Measurement

    effective range

    PAL/25Hz,-10℃-50℃

    Temperature range

    -20℃-150℃

    Accuracy

    ±2℃ or ±2% of reading for ambient temperature 15°C to 35°C

    Power System

    Power supply

    DC:4-6V

    Power consumption

    ≤1.5W@5V@25℃

    Environmental Parameters

    Environmental Parameters

    Operating temperature

    -40℃-70℃

    Storage temperature

    -45℃-85℃

    Certification

    RoHS,REACH,WEEE

    EMC

    FCC/CE/ClassB

    Physical Characteristics

    Size

    44.5mm×44.5mm×36.35mm

    Weight

    90g
